Metal workshops / steel construction
Stierli-Bieger has been an indispensable help to metal workshops and metal construction companies for decades. As a combined straightening and bending machine, the Stierli machine reliably carries out the straightening and bending work required. Complex bending by hand is no longer required. Unlike straightening by flame, straightening is fast, controlled and efficient.
A wide range of tools, such as bending tools, straightening tools, pipe bending and special tools, can be set up in an instant. The Stierli bending machine does not take up much space and, thanks to its mobile design, it can be positioned wherever it is required.
In many countries, the STIERLI BENDING MACHINE is regarded as a standard machine and is a MUST in any good workshop.
13 Article
Product comparison added Product comparison added Go to product comparison
Product was already added The product was already added. Please add another product or go to the Product comparison
Product comparison added The product has been added to the comparison. Please add at least one more product to start the product comparison.
| Working power | 12 to / 120 kN |
|---|---|
| Tooling height | 130 mm / 5" (inch) |
| Bending capacity flat | 130 / 12 mm |
| Straightening capacity | light straightening work |
| Pipe bending | 3/8" - 1 ½" |
| Round bar | ø 25 mm |
| Control | Manual control |
| Working power | 12 to / 120 kN |
|---|---|
| Tooling height | 130 mm / 5" (inch) |
| Bending capacity flat | 130 / 12 mm |
| Straightening capacity | light straightening work |
| Pipe bending | 3/8" - 1.5" |
| Round bar | ø 25 mm |
| Control | CNC Control |
| Working power | 22 to / 220 kN |
|---|---|
| Tooling height | 130 mm / 5.11" (inch) |
| Bending capacity flat | 130 / 16 mm |
| Straightening capacity | HEB 100 |
| Pipe bending | 3/8" - 1 ½" |
| Round bar | ø 30-35 mm |
| Control | NC control |
| Working power | 22 to / 220 kN |
|---|---|
| Tooling height | 130 mm / 4.72" (inch) |
| Bending capacity flat | 130 x 16 mm |
| Straightening capacity | HEB 100 |
| Pipe bending | 3/8" - 1 ½" |
| Round bar | ø 35 mm |
| Control | CNC Control |
| Bending capacity round bar | ø30 mm (S235) |
|---|---|
| Turning table ø | 390 mm / 550 mm |
| Torque | 2'450 Nm |
| Tooling height | 100 mm |
| Bending capacity flat | 60x15 / 50x20 |
| Bending capacity round bar | ø50 mm (S235) |
|---|---|
| Turning table ø | 390 / 550 / 1600 mm |
| Torque | 2'450 Nm |
| Tooling height | 100 mm |
| Bending capacity flat | 100x25 / 80x30 mm |
| Bending capacity round bar | ø 40 mm (S235) |
|---|---|
| Turning table ø | 390 mm |
| Turning table ø optional | 550 mm |
| Torque | 5'000 Nm |
| Tooling height | 100 mm |
| Bending capacity flat | 100x20 / 40x30 (S235) |
| Working power | 42 to / 420 kN |
|---|---|
| Tooling height | 200 mm / 7.87" (inch) |
| Bending capacity flat | 200 / 20 mm |
| Straightening capacity | HEA 180 |
| Pipe bending | 3/8" - 2" (60.3mm) |
| Round bar | ø 40 mm |
| Control | Manual control |
| Typical applications | Metalwork shop / metal construction for bending and straightening |
| Working power | 42 to / 420 kN |
|---|---|
| Tooling height | 200 mm / 7.87" (inch) |
| Bending capacity flat | 200 / 20 mm |
| Straightening capacity | HEA 180 |
| Pipe bending | 3/8" - 1 ½" |
| Round bar | ø 35 mm |
| Control | CNC Control |
| Working power | 82 to / 820 kN |
|---|---|
| Tooling height | 300 mm / 11.81" (inch) |
| Bending capacity flat | 300 / 20 (30) mm |
| Straightening capacity | HEA 260 |
| Pipe bending | 3/8" - 3" |
| Round bar | ø 60 mm |
| Control | Manual control |
| Typical applications | Metal construction, strong universal bending machine |
| Working power | 82 to / 820 kN |
|---|---|
| Tooling height | 300 mm / 11.81" (inch) |
| Bending capacity flat | 300 / 20 (30) mm |
| Straightening capacity | HEA 260 |
| Pipe bending | 3/8" - 3" |
| Round bar | ø 60 mm |
| Control | CNC Control |
| Working power | 130 to / 1300 kN |
|---|---|
| Tooling height | 300 mm / 11.81" (inch) |
| Bending capacity flat | 300 / 30 (40) mm |
| Straightening capacity | HEB 300 |
| Pipe bending | 3/8" - 3" |
| Control | Manual control |
| Typical applications | Metal construction, strong universal bending machine |
| Working power | 130 to / 1300 kN |
|---|---|
| Tooling height | 300 mm / 11.81" (inch) |
| Bending capacity flat | 300 / 30 (40) mm |
| Straightening capacity | HEB 300 |
| Pipe bending | 3/8" - 3" |
| Control | CNC Control |
