Horizontal bending machine - hydraulic press brake, metal brake, metal bender
Powerful universal bending machine that will impress you:
With its various tool solutions, the Stierli bending machine is very versatile. Its open design provides plenty of advantages for manufacturing bent parts. As a universal bending machine, the Stierli bending machine is used in numerous industries and for both single part/small series production and series manufacturing. Various control concepts, including manual and powerful CNC control systems, provide the operator with optimal support in the production process.
> See here the complete overview for the horizontal bending machines and press brake
Only a few applications for the Stierli horizontal bending machine:
> see the full application overview
for bending frames (with notches)
Manual and cnc bending machines:
as a hydraulic press for metal bending, sheet bend, sheet metal brake and metal bender
as a hydraulic press brake for metal bending, sheet bend, sheet metal brake and metal bender
The Stierli horizontal bender impresses with its countless advantages:
- Larger and wider working table
The working area has generous dimensions, which means that larger bending parts can be positioned securely. - Robust machine design
The rigid, robust design of the machine guarantees precise working with excellent long-term accuracy. - Long cylinder stroke with large insertion width
When it comes to aligning welded structures or using special tools, having sufficiently large stroke and insertion width is a big advantage. - High repeat accuracy
The combination of a very rigid machine design, precise hydraulics and the use of high-quality control components results in high repeat accuracy. - Very strong cylinder guiding system
The very strong cylinder design means that open guides are not required. The entirely enclosed guide system offers many advantages that help to maintain a long service life and long-term accuracy:
- The guide system is protected against wear
(in contrast to open guides)
- No additional lubrication required, no need for servicing.
- Our guide concept allows the working table to be completely enclosed
(see next point) - Precise, enclosed working table
The mechanically finished machine table provides a flat, clean surface. It is completely enclosed and does not require any openings for additional guides. As a result, small bending parts do not become jammed and scale cannot enter the guide system. - Little space required
The compact design means that the Stierli bending machine can be used anywhere in the workshop. - Movable with pallet lift truck or crane
If necessary, the Stierli bending machine can be moved easily to wherever it is required. - Compact, flexible and robust quality tools
Stierli-Bieger offers tools which, on the one hand, allow fine machining with small leg lengths, small U, L or Z bending dimensions. On the other hand, heavy-duty, strong bending tools are available for heavy bending machining. - Universal application
Numerous tools are available, offering an enormous production potential.
- Quick-change tool system
Changing tools takes a matter of seconds. - High bending output (up to 600 bends/hour)
In many cases, a Stierli bending machine is more cost-effective - Technical advantages and cost benefits over vertical press brakes.
The Stierli bending machine often has its nose ahead. More cost-effective, faster and more compact production is just one of the many arguments in favour of a Stierli bending machine. Find out more here. - User-friendly control.
Our controls are designed in such a way that the operator can learn how to use them very quickly.
The manual control system is very popular and has been tried and tested in deployment over decades. The control system can be picked up in just a few minutes. The manual control system allows very precise working with its fine stroke setting.
The modern, powerful CNC control system has a clearly designed multiple line display. Graphical symbols support and facilitate the operating process. - Cost-effective purchase in terms of uses and service life
The Stierli bending machine is mainly used as a production machine with outstanding cost effectiveness. The long service life of a Stierli bending machine increases the cost effectiveness of this investment further.
However, there are also some companies that use the Stierli bending machine to make prototypes or small series, or for occasional uses.
Such companies appreciate the constant availability of the Stierli bending and straightening machine, as they do not have to depend on external production service providers and thus have greater flexibility, enabling them to offer services and supply products more quickly. - Easy loading of the workpieces
The open design with large insertion width allows easy loading and parts handling. For large, heavy or long-sided parts, crane loading is an option.
